Definium™ 656 HD

The 12” touch screen OTS console has all the functionality you need to stay close to the patient while completing exam setup and positioning:

• Worklist management and patient selection
• Protocol selection
• Technique modification
• Positioning setup

• Skip the protocol selection screen. Once the exam is started, Auto Protocol Assist (APA)† will automatically establish the requested exam procedure according to the information from the Modality Worklist.
• Skip initial collimation. Auto Field of View† sets the size and orientation of the collimation automatically based on the procedure and view that has been selected.

Easy-to-use features help technologists save time with less walking, less manual exertion, and faster equipment movement.

• Auto Positioning – The OTS, table, and wall stand automatically move to predefined locations based on the selected procedure and view.
• Auto Centering – The OTS automatically moves to the center of the wall stand's current position or the center of the table detectors current position.

• Auto-Tracking – The OTS automatically moves vertically to follow the wall stand movement, and the table detector housing automatically follows the OTS longitudinal movement and adjusts position for changes in angulation.
• Reverse Tracking – The wall stand follows the OTS movement, even with angulation.
• OTS automatically moves vertically to maintain SID with table.

Overlays are available on any patient anatomy and view, with real-time adjustments, so the placement is correct regardless of the patient size or parallax effects.

• See exactly where the ion chambers will align for confident patient positioning.
• See which ion chambers are active for direct alignment to appropriate anatomy.
• Works at the table or wall stand, even when the tube is angulated.

• Improve x-ray technique based on patient size for improved image quality and dose.
• Works on 30 anatomy/view combinations, including: abdomen, chest, pelvis, and spine – at the table or wall stand.
• Displays measured thickness and automatic pop-up of suggested patient size.
• Each habitus is programmable for different size ranges according to site specific needs.

The system attaches an optical picture as a secondary DICOM capture when sent to the PACS, providing contextual awareness of the exam conditions for the radiologist:

• Presence of external objects, such as lines and clothing.
• Positioning limitations and patient orientation.
• Deviations from ideal imaging conditions.
• Specifics of the x-ray acquisition parameters.

At 100 micron pixels, FlashPad HD detectors provide 4x higher resolution than 200 micron pixel detectors, helping to distinguish fine structures.

• Exceptional dose efficiency with 75% DQE at 0 lp/mm.
• Choice of 3 sizes: 17 x 17 inch, 14 x 17 inch or 10 x 12 inch.
• Always ready when you need them – detectors automatically charge in their holders and connect wirelessly to registered systems.

• View weight bearing and pediatric obstruction studies at a lower dose than CT.
• Obtain multiple cross-section images of the anatomy in a single sweep at a low dose, including chest, abdomen, extremities, spine, skull and sinuses.
• Resolve inconclusive x-rays in orthopedic and trauma cases efficiently.
• Achieve superior lung nodule detection sensitivity compared to conventional chest x-ray.

• Coverage at wall stand for 2-5 images, up to 150 cm (59 in).
• Coverage at the table for 2-4 images, up to 110 cm (43 in).
• Acquisition ≤10 seconds, stitched image ≤22 seconds for 3 images, up to 90 cm (35.4 in) coverage.
• No parallax.
• Auto Spine algorithm follows the contour of the spine for vertical equalization, enabling a natural balance of brightness and contrast along the patient body.

• AI-driven automated brightness and contrast (AIBC) delivers improved consistency despite variations in exposure technique and challenging exam conditions.
• Detail Preserving Noise Reduction Filter (DPNR) delivers significant noise reduction capabilities, while minimizing the effect on fine details.
• Local Contrast Enhancement (LCE) delivers improved contrast for chest, ankle joint, foot, and patella images.

• Real-time IP Looks – Allows for faster and easier fine-tuned customizations. Custom IP Looks can be set as the default look, or the look achieved with the QuickEnhance tool.
• IQ Compare – Allows for simultaneous viewing of the standard and customized looks to simplify comparisons between the different options.
• QuickEnhance – Provides one-touch reprocessing of images with a custom look.
